Observation on the Formation and Composition Analysis of Blue Pollen of Caryopterisincana

doi:10.7525/j.issn.1673-5102.2023.05.016

Abstract

Abstract:

In majority of plants， colorful pollen is rarely seen on the surface of pollen except light yellow. In this article， the existence of blue pollen was discovered in Caryopterisincana， and the color of anther and pollen at different developmental stages was observed by microscope， and the anthocyanin components of mature pollen were analyzed by UPLC/MS（Ultra Performance Liquid Chromatography-tandem mass spectrometry）. The results showed that mature anthers and pollens were blue due to the rich anthocyanins. The color of anther and pollen changed obviously at young buds， early flowering buds and flowering stages， which were light yellow， light blue and blue purple respectively. The blue pigments of pollen mainly existed in the surface of pollen coat and tapetal cells by the cross-section observation. The UPLC/MS analysis showed that there were six kinds of anthocyanins on the pollen surface at the flowering stage， among which the main blue components were Delphinidin 3-O-glucoside and Malvidin 3，5-O-diglucoside， followed by Peonidin， Cyanidin and Petunidin， while the content of Pelargonidin was the lowest.

Key words: Caryopterisincana, anther, pollen, anthocyanin

CLC Number:

Q949.777.6

Qinghua YANG, Binjie GE, Dasheng ZHANG. Observation on the Formation and Composition Analysis of Blue Pollen of Caryopterisincana[J]. Bulletin of Botanical Research, 2023, 43(5): 794-800.

Figures/Tables 4

Fig.1

Fig.2

Table 1

Fig.3

References 24

1	田惠桥，朱学艺.被子植物生殖生物学［M］.北京：科学出版社，2012：16-17.
	TIAN H Q， ZHU X Y.Reproductive biology of angiosperms［M］.Beijing：Science Press，2012：16-17.
2	SCOTT R J， SPIELMAN M， DICKINSON H G.Stamen structure and function［J］.The Plant Cell，2004，16（suppl.1）：S46-S60.
3	朱骏，杨仲南.花粉壁发育研究进展［J］.自然杂志，2013，35（2）：112-117.
	ZHU J， YANG Z N.The research progress of pollen wall development［J］.Chinese Journal of Nature，2013，35（2）：112-117.
4	PACINI E， HESSE M.Pollenkitt-its composition，forms and functions［J］.Flora，2005，200（5/6）：399-415.
5	BLACKMORE S， WORTLEY A H， SKVARLA J J，et al.Pollen wall development in flowering plants［J］.New Phytologist，2007，174（3）：483-498.
6	XU T， ZHANG C， ZHOU Q，et al.Pollen wall pattern in Arabidopsis ［J］.Science Bulletin，2016，61（11）：832-837.
7	MILLER R， OWENS S J， RØRSLETT B.Plants and colour：flowers and pollination［J］.Optics and Laser Technology，2011，43（2）：282-294.
8	HANSEN D M， OLESEN J M， MIONE T，et al.Coloured nectar：distribution，ecology，and evolution of an enigmatic floral trait［J］.Biological Reviews，2007，82（1）：83-111.
9	HESLOP-HARRISON J.Anther carotenoids and the synthesis of sporopollenin［J］.Nature，1968，220（5167）：605.
10	WIERMANN R， GUBATZ S.Pollen wall and sporopollenin［J］.International Review of Cytology，1992，140：35-72.
11	BAKÓ E， DELI J， TÓTH G.HPLC study on the carotenoid composition of Calendula products［J］.Journal of Biochemical and Biophysical Methods，2002，53（1/2/3）：241-250.
12	WAKELIN A M， LISTER C E， CONNER A J.Inheritance and biochemistry of pollen pigmentation in California Poppy （Eschscholzia californica Cham.）［J］.International Journal of Plant Sciences，2003，164（6）：867-875.
13	FAMBRINI M， MICHELOTTI V， OrangePUGLIESI C.，yellow and white-cream ：inheritance of carotenoid-based colour in sunflower pollen［J］.Plant Biology，2010，12（1）：197-205.
14	ZHANG D S， CHEN Q， LIU Q Q，et al.Histological and cytological characterization of anther and appendage development in Asian lotus（Nelumbo nucifera Gaertn.）［J］.International Journal of Molecular Sciences，2019，20（5）：1015.
15	ALBERT N W， LEWIS D H， ZHANG H B，et al.Light-induced vegetative anthocyanin pigmentation in Petunia ［J］.Journal of Experimental Botany，2009，60（7）：2191-2202.
16	洪艳，武宇薇，宋想，等.光照调控园艺作物花青素苷生物合成的分子机制［J］.园艺学报，2021，48（10）：1983-2000.
	HONG Y， WU Y W， SONG X. et al.Molecular mechanism of light-induced anthocyanin biosynthesis in horticultural crops［J］.Acta Horticulturae Sinica，2021，48（10）：1983-2000.
17	李瀚纯，张大生，刘青青，等.观赏植物蓝色花形成的机制［J］.亚热带植物科学，2021，50（2）：155-162.
	LI H C， ZHANG D S， LIU Q Q，et al.Formation mechanism of blue flowers in ornamental plants［J］.Subtropical plant Science，2021，50（2）：155-162.
18	GOMEZ C， CONEJERO G， TORREGROSA L，et al. In vivo grapevine anthocyanin transport involves vesicle-mediated trafficking and the contribution of anthoMATE transporters and GST［J］.The Plant Journal，2011，67（6）：960-970.
19	GOODMAN C D， CASATI P， WALBOT V.A multidrug resistance-associated protein involved in anthocyanin transport in Zea mays ［J］.The Plant Cell，2004，16（7）：1812-1826.
20	MARRS K A， ALFENITO M R， LLOYD A M，et al.A glutathione S-transferase involved in vacuolar transfer encoded by the maize gene Bronze-2 ［J］.Nature，1995，375（6530）：397-400.
21	MUELLER L A， GOODMAN C D， SILADY R A，et al.AN9，a petunia glutathione S-transferase required for anthocyanin sequestration，is a flavonoid-binding protein［J］.Plant Physiology，2000，123（4）：1561-1570.
22	JORGENSEN T H， PETANIDOU T， ANDERSSON S.The potential for selection on pollen colour dimorphisms in Nigella degenii：morph-specific differences in pollinator visitation，fertilisation success and siring ability［J］.Evolutionary Ecology，2006，20（4）：291-306.
23	LAU J A， GALLOWAY L F.Effects of low-efficiency pollinators on plant fitness and floral trait evolution in Campanula americana （Campanulaceae）［J］.Oecologia，2004，141（4）：577-583.
24	KOSKI M H， GALLOWAY L F.Geographic variation in pollen color is associated with temperature stress［J］.New Phytologist，2018，218（1）：370-379.

序号 No.	成分类别 Composition	质量分数 Mass fraction/（μg·g^-1）
1	矢车菊素-3，5-O-二葡糖苷Cyanidin 3，5-O-diglucoside	0.098±0.009
2	矢车菊素-3-O-葡糖苷Cyanidin 3-O-glucoside	0.536±0.193
3	飞燕草素-3-O-半乳糖苷Delphinidin 3-O-galactoside	0.059±0.027
4	飞燕草素-3-O-葡糖苷Delphinidin 3-O-glucoside	1.720±0.260
5	锦葵色素-3，5-O-二葡糖苷Malvidin 3，5-diglucoside	1.071±0.381
6	锦葵色素-3-O-葡糖苷Malvidin 3-O-glucoside	0.010±0.009
7	天竺葵色素-3，5-O-二葡糖苷Pelargonidin 3，5-O-diglucoside	0.212±0.074
8	天竺葵色素-3-O-丙二酰葡糖苷Pelargonidin 3-O-（6-O-malonyl-β-D-glucoside）	0.044±0.009
9	天竺葵色素-3-O-葡糖苷Pelargonidin 3-O-glucoside	0.039±0.019
10	芍药花色素-3，5-O-二葡萄糖苷Peonidin 3，5-O-diglucoside	0.114±0.032
11	芍药花色素-3-O-葡糖苷Peonidin 3-O-glucoside	0.749±0.328
12	矮牵牛花色素-3，5-O-二葡糖苷Petunidin 3，5-O-diglucoside	0.055±0.028
13	矮牵牛花色素-3-O-丙二酰葡糖苷Petunidin 3-O-（6-O-malonyl-β-D-glucoside）	0.287±0.083
14	矮牵牛素-3-O-葡糖苷Petunidin 3-O-glucoside	0.119±0.035
